Two Working Mode (Cool & Heat)

√ Cooling Mode：If Measured Temperature ≥ (setting temp. + temp. difference), the cooling process will operate. Otherwise, the cooling process will stop.
√ Heating Mode: If Measured Temperature ≥ (setting temp. + temp. difference), the heating process will stop. Otherwise, it will start.


Parameters:

* Temperature Measuring Range: -40℃ to 100℃
* Temperature Control Range: 16℃ to 40℃
* Resolution: 0.1℃
* Accuracy: +/- 1℃
* Ambient Requirements: -10℃ to 60℃, 20% to 85% (humidity)
* Product Consumption: ≤ 3W
* Input Voltage: 110V ac
* Output: resistive load≤1100W/110V, inductive load≤138W/110V, filament lamp≤110W/110V
* Sensor Cable Length: 39.4"
* Item Size: 5.32 * 2.17 * 1.38"


Q&A:

Q1: How to switch between HEAT/COOL mode?
A1: Press H/C Key to switch the mode between HEAT and COOL in normal working status.

Q2: How to set up DIFF (Temperature Difference)?
A2: Press SET Key in normal working status to display the default DIFF value while icon DIFF flashing, then press UP or DOWN Key to adjust the ideal temperature difference you want.

Q3: How to set up DELAY (Compressor Delay)?
A3: Press SET Key to display the default DELAY value while icon DELAY flashing, then press UP or DOWN Key to adjust the ideal compressor delay time you want. Then press SET to save and exit.

Q4: How to set up the temperature?
A4: Press UP or Down Key in normal working status to display the default stop temperature value while icon ℃ flashing, then press UP or DOWN Key to adjust the ideal stop temperature you want.

Q5: How to switch between Celsius and Fahrenheit?
A5: Press SET key in normal working status for 5 seconds.
　

• Dual working modes: COOL & HEAT
• Adjustable output delay function to protect compressor
• Support reading with Centigrade or Fahrenheit unit
• Plug and play design, easy to use
• Widely used in aquarium, reptile market, incubators, green house, refrigerator etc
